PSE 300 2VL

PSE 300 2VL
Economy cleaning system for screens, stencils, PumPrint stencils

The kolb PSE economy line is a quality series of advanced cleaning systems, which focuses on all essential criteria for a qualified cleaning process and therefore stands for attractive purchase prices.

kolb PSE 300 2VL is a fully automatic system for reliable precision cleaning of screens, stencils, PumpPrints or other flat products. Removes quickly and thoroughly contaminations such as SMD-paste, SMD-adhesive, flux residues, stabilizer materials, flux, oil, grease or dust.

PSE 300 2VL is a German engineered and manufactured machine with ClosedLoop water reprocessing and a two-tank and two separate circuits configuration which ensures short cycle times and makes this system the perfect economic choice for the cleaning of screens and stencils.

Highlights

Two tank system with two separate circuits
Comfortable push-one-button operation
Fully automatic 4step process: cleaning, MediumWipe^®, rinsing (tap water), CWA^® supercharger compression drying
Vertical rotor system with asynchronous spray rotors for thorough wetting (no blind spots)
Short cycle times due to placing the cleaning goods close to the spray rotors
Permanent filtration
ClosedLoop reprocessing of cleaning and rinsing fluids as standard feature
Water-free operation possible: Instead of water the system can use a suitable cleaning / rinsing detergent for rinsing
Process and service intervals PLC controlled
Event issuing and software control via high resolution 7" display with capacitative multi-touch
All safety relevant devices are standard features in the basic system configuration
Extremely compact - very small footprint

Technical data
Technology base	kolb PowerSpray^®
Control system (Display size)	PLC - Eaton (7“)
Standard capacity (per process cycle)	21 eurocards or one coating carrier, screen, stencil, (PCB-) carrier/ washing frame up to 770 x 950 mm (30" x 37")
Process chamber dimensions	W 350 mm • D 980 mm • H 920 mm
Clamping space for PCBA, Misprints etc.	H 730 mm x W 525 mm
Max. stencil, carrier, washing frame size	H 770 mm x W 950 mm
Circuits	2+ Cleaning, Rinsing tap water / Rinsing DI-water (combined)
Volume Tank A	75 l • Cleaning
Volume Tank B/C	75 l • Rinsing tap water / Rinsing DI-water (combined)
Max. cleaning temperature	50 °C (122 °F)
Filtration	Up to three stages - 1. Full flow coarse filter < 2 mm, 2. Cascaded sediment filter inside the tank, 3. 20“ fine filter (1 - 100 µm - process dependent)
Drying System	CWA^® supercharger
Drying temperature range	Compressed warm air
Power supply	400 V AC, 16 A, CEE plug / 3 Ph / 50 or 60 Hz
Power consumption	4 kW
Supply connection 1 (tap water)	1/2“
Supply connection 3 (Compressed Air)	8 mm (87 - 116 psi - 100 l / min)
Empty Weight	570 kg (1,257 lbs)
Footprint	950 mm x 1600 mm (37.40″ x 62.99″)

Certifications

ENERSAVE certified

kolb cleaning systems are ENERSAVE certified for offering top performance and using less energy than any comparable competitor product.

WATERSAVE certified

The kolb technologies ClosedLoop and CrossLoop are WATERSAVE certified and save significantly water by recycling contaminated rinsing liquids.

EASOTECH certified

EASOTECH assures state of the art technology with the easiest possible operation of complex engineering performance and intelligent software design.

SAFEGAR certified

The 5-star SAFEGAR certificate ensures that all relevant safety and protective functions are included in the standard version of every kolb cleaning system.

Smart Fatory ready / Standard

Smart Factory ready economy systems can be equipped with a basic traceability function and thus be easily integrated into industry 4.0 production environments.
